LoRaWAN Smart Circuit Breaker
Our best smart circuit breaker system is a state-of-the-art solution for managing electrical power distribution in homes and commercial buildings. It features advanced technology that integrates with smart home systems and allows users to monitor and control their electrical circuit breaker from their smartphone or tablet. The system also offers real-time energy monitoring and analysis, providing insights into energy consumption patterns and helping users to save energy and reduce costs.
Additionally, the smart circuit breaker system includes advanced safety features such as over-current protection and surge protection, ensuring the safety of electrical systems and appliances. With its sleek design, easy installation and user-friendly interface, the Smart Circuit Breaker System is a must-have for any modern and connected home or building.
Features of Product
Connected to the server to remote control by app application.
Highly integrated,easy networking, easy to expand and easy construction.
Max communication distance up to 11km by LoraWan communication technology.
Collecting information of electricity consumption and monitoring inforamtion of electricity consumption such as time, electricity, power, power factor, etc.That guide users enhance power safety and improve energy efficiency.
Compatible with standard LoRaWAN gateways and third-party network server platforms .
HKT provides customized services:
Product Specifications
| Parameters | Description |
| Local leakage self-test | Support self-test by manual |
| Mobile phone operating leakage self-test | Support self-check by mobile application |
| Leakage self-test | Support any specified date and time every month detection automatically |
| Delivery of current automatically | Support automatic delivery of current after self-test |
| Voltage, current, leakage current monitoring | Support query of voltage, current and leakage current data in real time |
| Power | Set the reached power valu cut-off |
| Short Circuit Protection | 5-10 times rated current, |
| 0.04secs short circuit protection | |
| Leakage protection | 30mAh leak current,0.1seconds circuit protection |
| Overload Protection | set rated current value,rated load power-off protection |
| Lack-voltage alarm | voltage<100V alarm |
| Overvoltage protection | voltage>250V/430V alarm，voltage>263V/456 power off protection |
| Outage alarm | strike a light alarm |
| Over temperature protection | monitoring the temperature in real-time;>70℃ alarm,>90℃blackout |
| Lightning surge protection | bleeder current 15KA |
| Push by manual | On/off control |
| Electric control | On/off control |
| Mobile Remote control | On/off control |
| Security Messages recording | Supports 12 months |
| Mobile APP Management | Support customer power safety and energy consumption management |
| PMS | Property current and voltage load fluctuation, electricity alarm |
| Battery Left | Support power metering, recording hourly, daily and monthly,12 months can be queried |
| OIT Interface | TCP/IP,RS485,Zigbee,NB-lot,2G |
| Connect Video Surveillance | Support docking app with any brand |
| Centralized management | Support centralized statistical analysis of smart power management &safety supervision platform |
Our best smart circuit breakers can be installed at the home power inlet side to measure electrical energy and remotely monitor status. At the same time, protect people and family property.
Installed in the guest room power distribution network. Smart circuit breakers not only protect people, but also protect hotel property. At the same time, it can minimize outages caused by anomalies, so as to improve customer satisfaction.
It is uniformly installed in the power distribution box in the corridor to protect the property safety of tenants and landlords. Smart circuit breakers not only realize the power metering and pre-payment functions, but also realize the purpose of recharging the electricity bill before use.
Smart circuit breakers can also be installed in distribution boxes outside the park. Able to remotely control street lights. Based on the timing function of the cloud platform, the street lamp can be powered and turned off regularly every day.
The distribution box is generally installed on the utility pole next to the farm to realize the remote control of street lamps and single metering.
HKT LoRaWAN Siren makes light and sound to tell the guard management there is an alert. It supports standard LoRaWAN protocol. It has high detection accuracy. With a durable shell, it has a long life span.
